Press Agglomerator

Type: WPA

With the WIPA Press Agglomerator type WPA, pioneering innovations make automatic Press Agglomerator possible, even with the most diverse materials.

Press Agglomerator

Automatic distance adjustment

The automatic distance adjustment of the pan grinder impellers to the die surface allows the material friction process (with heat factor) for compaction to be shifted to the pan grinder chamber instead of in the die bores and enables changes in the quality of the pellets during operation. This friction shift enables significant tool savings by eliminating the need for adapted die thicknesses for a fixed pellet quality. With the automatic distance adjustment, a pelletizing process can be carried out that produces a homogeneous final pellet from different input pellets, which is important for the pellet and pellet quality. The frictional conditions make it possible to break down composite materials in a way that would otherwise be difficult. The latter process is mainly used with short die holes of 10 – 16 mm.

Automatic control of the speed of the roller impellers

The speed of the pan grinder impellers is controlled fully automatically and synchronized with the infeed. The recipe preselection for a specified PELLET quality. The recipes enable variable material distribution between the pan grinder wheels and variable material strokes in the die and ensure consistent pellet quality.

Die cooling

If the temperature specification is exceeded, cooling with an adjustable die range is automatically switched on. If the material pressure between the pan grinder and die does not drop to the specified pressure, e.g. with wood, paper and biowaste, a liquid/water mist device with adjustable dosing can be switched on automatically. In addition, other liquids can be added to enhance the pelleting process.

Cooling

Activation of the die cooling device according to the temperature specification range.

Connection of water mist device.

Pellet length

The speed of the knock-off device located under the die can be infinitely adjusted,
This allows different individual lengths of pellets to be generated.

Function monitoring

Automatic function monitoring with oil cooling, overload protection with soft start included. Reversing control of the roller head is standard. A round silo with discharge cone and coreless, power-controlled discharge screw is used to ensure uniform dosing of the material quantity.

Outstanding processing diversity

Wood

Plastic

Cellulose

All data at a glance

Drive motor
37 – 45 KW
Drive unit
mechanical
Die diameter
600 mm
Roll diameter
250 mm
Die hole diameter
4 – 16 mm
Pellet length
5 – 25 mm
Weight
approx. 1800 kg
Throughput
up to 600 kg/h input
(depending on bulk density and pellet diameter)

Throughput rates and technical data are based on experience and may vary depending on the material.
